Nidec變頻器 C300-04400170A

登錄可見

Nidec

自營詳情

產品圖片
品牌/名稱/型號
價格/庫存/銷量
產品簡述
查看詳情

Nidec
Nidec變頻器 C300-04400170A
登錄可見

1種產品

庫存:期貨銷量:2

翻譯結果

C300 系列于 2019 年推出，是 Control Techniques 非常成功的 Commander 系列變速驅動器的最新版本。 Commander 系列于 1983 年首次推出，現已成為運動控制領域的卓越標準。這個最新的迭代建立在幾十年的知識基礎上，并將其與自動化領域的尖端技術相結合。

C300 系列專為廣泛的一般應用而設計。安裝和調試簡單——Commander C 驅動器可以在幾秒鐘內使用驅動器正面列出的關鍵參數功能進行設置。如果您在開始使用 Control Techniques 時需要一些幫助，可以從 Drive-Setup.com 獲得許多免費的“操作方法”指南。我們 InvertersUK (Goodwin Electronics) 還為我們銷售的所有驅動器提供免費電話支持。板載 PLC – 嵌入式控制器無需外部智能系統，從而節省空間和金錢。堅固可靠的設計 – Commander C 驅動器具有許多尖端設計功能，例如智能風扇故障檢測系統、跳閘避免功能和高過載能力，因此經久耐用。集成 EMC 濾波器 – 每個 Commander C 驅動器都配備符合 EN/IEC 61800-3 標準的濾波器，以幫助減少線路上的電氣“噪聲”。

技術規格 / Technical Specification

Model Number		C300-04400170A
Voltage Class		400 V
Supply Phase		3ph
Heavy Duty	Max. Continuous Current (A)	17.0
	Max. Power (kW)	7.5
	Motor Power (HP)	10
Normal Duty	Max. Continuous Power (A)	–
	Max. Power (kW)	–
	Motor Power (HP)	–

交流電源要求 / AC Supply Requirements

Voltage	200 V models: 200 to 240 VAC ±10% 400 V models:380 to 480 VAC ±10%
Maximum Supply Imbalance	2% negative phase sequence, 3% voltage imbalance between phases
Input Frequency	45 to 66 Hz
Input Displacement Power Factor	0.97

控制 / Control

Switching Frequency	Frame size 1-4: 0.667, 1, 2, 3, 4, 6, 8, 12 & 16 kHz Frame size 5-9: 2, 3, 4, 6, 8, 12 & 16 kHz
Output Frequency Range	0 to 550 Hz
Frequency Accuracy	±0.02% of full scale
Frequency Resolution	0.01 Hz
Analog Input Resolution	Voltage mode: 11 bits (unipolar) Current mode: 11bits
Braking	Dynamic braking transistor included, requires external resistor

保護 / Protection

DC Bus Undervoltage Trip	200 V models: 175 Vsc 400 V models: 330 Vdc
DC Bus Overvoltage Trip	Frame sizes 1 – 4: 200 V models: 510 Vdc 400 V models: 870 Vdc
DC Bus Overvoltage Trip	Frame sizes 5 – 9: 200 V models: 415 Vdc 400 V models: 830 Vdc
Drive Overvoltage Trip	Programmable: Default settings: 180% for 3s, 150% for 60s
Instantaneous Overcurrent Trip	200% of rated motor current
Phase Loss Trip	DC bus ripple threshold exceeded
Over-temperature Trip	Drive heatsink temperature exceeds 95°C
Short Circuit Trip	Protects against output phase-to-phase fault
Group Fault Trip	Protects against output phase-to-ground fault
Motor Thermal Trip	Electronically protects the motor from overheating due to loading conditions

操作環境 / Operating Environment

Cooling Method	Forced convection
Ambient Operating Temperature	Size 1 – 4: -20 to +40°C at 3 kHz switching frequency \| Operation at 60°C with de-rating Size 5 – 9: -20 to +40°C at 3 kHz switching frequency \| Operation at 55°C with de-rating
Humidity	95% non-condensing at 40°C
Storage Temperature	Size 1 – 4: -40 to +60°c – 24 months max. Size 5 – 9: -40 to +55°c – 24 months max.
Altitude	De-rated the continuous output current by 1% for every 100m above 1000m to a maximum of 3000m
Enclosure Rating	IP20. NEMA 1 conduit kits available
